CEW Steel Tubes

Top Notch Manufacturer of Stainless and Carbon Steel Cold Drawn ERW Tube

CEW Steel Tubes

CEW Steel Tubes

Carbon Steel Cold Drawn ERW Tube

Carbon Steel Cold Drawn ERW Tube

Steel cew-1 tubes

Steel cew-1 tubes


Buy Cew Tube Material Price

Table of Content


Material Specification of CEW Steel Tubes

Standard ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB
Outer Dimensions 4.0mm – 60.0mm
size 5.0 - 1219.2 mm
Swg & Bwg 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Schedule SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length Single Random, Double Random, Standard & Cut length Pipe
Finish Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc
Form are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc.
Types Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW
End Plain End, Beveled End, Treaded Pipe, Screwed ends
Value Added Service Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc.
manufacturing Technique Cold drawn, hot drawn, bright annealed, solid solution, hot extruding
Test Certificate Manufacturer Test Certificate
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection

Basic types of Steel cew-1 tubes

Cold Drawn 316L Stainless Capillary Steel Tube

Cold Drawn 316L Stainless Capillary Steel Tube

CEW tube material

CEW tube material

Cold Drawn ERW Tube

Cold Drawn ERW Tube

Cold Drawn E355 St52 Pipe And Tube

Cold Drawn E355 St52 Pipe And Tube

CEW material

CEW material

CEW sin pipe

CEW sin pipe

IS 3074 CDW Steel Tubes

IS 3074 CDW Steel Tubes

CEW Oil Draw Tubes

CEW Oil Draw Tubes


Chemical Equation of Cold Drawn ERW Tube

GRADE C % Si % Mn % P&S %
CEW 2 0.16 max   0.70 max 0.050 max
CEW 3 0.20 max 0.35 max 0.90 max 0.050 max
CEW 4 0.25 max 0.35 max 1.20 max 0.050 max
CEW 5 0.23 max 0.50 max 1.50 max 0.050 max

steel cew-1 tubes exporter in India

Mechanical Behaviour of Carbon Steel Cold Drawn ERW Tube

Condition Yield Tensile Elongation
  Re min N/mm2 Re min N/mm2 min %
BK as drawn 320 400 6
GBK annealed 150 270 27
NBK normalised 155 280 25

CEW sin pipe Dimensions

O.D Wall 0.71 0.81 0.91 1.22 1.42 1.63 2.03 2.34 2.64 2.95 3.25 4.06 4.76 4.88 6.35 7.94 9.53 12.70
4.76 –
6.35 –     x x   x
7.94 –     x x   x x
9.53 –     x x x x x   x   x
11.11 –     x x x x x
12.70 –     x x x x x   x   x
14.29 – x   x x   x x   x x x
15.88 –     x x   x x   x x x x   x
17.46 –     x     x x       x
19.05 –       x   x x   x x x x   x x
20.64 –           x x       x
22.22 –       x x x x   x x x x   x x
25.40 –       x x x x x x x x x   x x
26.99 –           x x       x x   x
28.58 –       x x x x   x   x x   x x
30.16 –           x x   x
31.75 –       x   x x   x   x x   x x x
33.34 –           x           x
34.93 –       x   x x   x   x x   x x x x
38.10 –           x x   x   x x   x x x x
39.69 –                     x     x
41.28 –           x x   x   x x   x x x x
42.86 –                 x   x
44.45 –           x x   x   x x   x x x x
47.63 –                 x   x x   x x x
50.80 –       x   x x   x   x x   x x x x
53.98 –                     x     x x x x
57.15 –             x   x   x x   x x   x
60.33 –           x         x x   x x x x
63.50 –             x   x   x x   x x x x
66.68 –                     x     x x
69.85 –                 x   x x   x x   x x
73.02 –           x
76.20 –           x x   x   x     x x x x x
79.38 –           x
82.55 –           x     x   x       x   x
88.90 –                     x       x x x
95.25 –                     x       x
101.60 –                     x x     x
107.95 –                     x       x
114.30 –                     x       x
127.00 –                     x             x

Size Range of CEW Oil Draw Tubes

Od/THK 0.9 1 1.22 1.42 1.5 1.63 1.85 2.03 2.34 2.64 2.95 3.25 3.66 4.06 4.65 5.5 6
15.88 0.332 0.367 0.441 0.506 0.532 0.573
19.05 0.403 0.445 0.536 0.617 0.649 0.700 0.785 0.852 0.964
22.2 0.473 0.523 0.631 0.728 0.766 0.827 0.928 1.010 1.145
23.42 0.500 0.553 0.668 0.770 0.811 0.876 0.984 1.095 1.216 1.482 1.633
25.4 0.544 0.602 0.728 0.842 0.884 0.956 1.074 1.250 1.244 1.585 1.749
28.58 0.614 0.680 0.823 0.951 1.002 1.083 1.220 1.329 1.422 1.689 1.865
31.75 0.685 0.758 0.919 1.062 1.119 1.211 1.364 1.488 1.697 1.895 2.095 2.284
33.7 0.728 0.806 0.977 1.130 1.191 1.289 1.453 1.585 1.810 2.022 2.237 2.441 2.711
34.93 0.756 0.837 1.015 1.174 1.237 1.339 1.510 1.648 1.882 2.104 2.328 2.541 2.824
38.1 0.826 0.915 1.110 1.285 1.354 1.466 1.654 1.806 2.064 2.309 2.557 2.793 3.109 3.408
40   0.962 1.167 1.351 1.424 1.542 1.741 1.901 2.173 2.432 2.695 2.946 3.280 3.599
41.28   0.993 1.205 1.396 1.472 1.594 1.799 1.965 2.247 2.516 2.789 3.048 3.396 3.727
44.45   1.072 1.301 1.507 1.589 1.721 1.944 2.124 2.430 2.722 3.019 3.302 3.682 4.044 4.564
49     1.438 1.666 1.757 1.904 2.151 2.351 2.693 3.018 3.350 3.667 4.092 4.500
50.8   1.228 1.492 1.729 1.824 1.977 2.233 2.442 2.797 3.136 3.481 3.811 3.255 4.680 5.292 6.144
57.15         2.059 2.232 2.523 2.759 3.163 3.549 3.943 4.320 4.828 5.316 6.020 7.006
60.3           2.358 2.667 2.917 3.345 3.754 4.172 4.573 5.112 5.631
63.5         2.294 2.487 2.813 3.077 3.529 3.962 4.405 4.829 5.401 5.951 6.749 7.867 8.508
65           2.547 2.881 3.152 3.616 4.060 4.514 4.949 5.537 6.102
69.85         2.528 2.742 3.102 3.395 3.896 3.376 4.867 5.338 5.974 6.587 7.477 8.728 9.448
76.2         2.763 2.998 3.392 3.713 4.262 4.789 5.329 5.847 6.548 7.223 8.205 9.590 10.387
81.2         2.948 3.199 3.620 3.963 4.551 5.115 5.693 6.248 6.999 7.724 8.778 10.268 11.127
82.5         2.996 3.251 3.680 4.029 4.626 5.199 5.787 6.352 7.116 7.854 8.928 10.444 11.320
88.9         3.223 3.508 3.972 4.349 4.995 5.616 6.253 6.865 7.694 8.495 9.661 11.312 12.267
101.3           4.019 4.551 4.985 5.728 6.443 7.177 7.883 8.840 9.766 11.118 13.035 14.146
114.3           4.529 5.130 5.621 6.461 7.270 8.101 8.901 9.986 11.038 12.574 14.757 16.025

Instant Delivery Available on Carbon Steel cew sin pipe At Discounted Price.

Features of IS 3074 CDW Steel Tubes

  • High precision
  • Dimensional tolerance
  • Superior strength
  • Easy installation
  • Controlled & uniform mechanical properties
  • Smooth surface finish

Distributors of Alloy Steel CEW Pipe, We Stock CEW Material in Different Sizes and Shapes

Applications of Cold Drawn E355 St52 Pipe

  • Steering Column
  • Two Wheeler Main Frame
  • Bottom Chassis
  • Fuel Tank Spacer
  • Swing Arm
